ZERO-I W Coating
(pronounced “Zero-One Double”)
- ZERO-I W Coating
-
By doubling the film thickness of ZERO-I, this
coating provides significantly improved wear
and heat resistance.
Applications include cold stamping, hot
stamping, ultra-high tensile steel forming,
cold/warm/hot forging, and die-casting molds.
ZERO-I W Coating is recommended in this field
Feature
- Excellent Wear Resistance and Strong Adhesion
The increased film thickness further enhances wear resistance while maintaining exceptional adhesion to the substrate.
- High Heat Resistance
The thicker film helps reduce thermal impact on the base material. It resists oxidation and wear even under high-temperature conditions, making it suitable for processes prone to galling or seizure, such as warm and hot forging or die-casting operations.
- High Surface Pressure Resistance
The coating maintains stable performance even under high surface pressure environments.
- Film hardness:：Hv2,500
- Heat-resistant temperature：700℃
- Coefficient of friction：0.40
- Operating temperature：500℃
- Recommended film thickness：4 - 6μm
