CrN coating

CrN coating

This is the standard for chrome coating and has excellent adhesion resistance, corrosion resistance, and slidability. The component elements are stable and may be used as a base for other coatings to prevent corrosion.

Improved adhesion/Corrosion resistance/Slidability
SUS mold/Die-cast pin
Cutting tool for non-ferrous metal/Automotive parts

CrN coating is recommended in this field

Corrosion resistancereleasablityLubricity/slidability/low frictionCold pressCold forgingPunching dieAparture moldPress fitting diesSUSprocessing moldPunch pinAutomotive partsIndustrial machine partsLow voltage partsFilm types of PVD coating

Feature

Heat-resistant

Hardness is inferior from TiN, but it has excellent heat resistance and slidability.

Corrosion resistance

The internal stress is lower than titanium, and stable coating with fewer pinholes. It is used in die-cast pins, resin molds, and rubber molds so on.

• Film hardness: Hv1,500
• Heat-resistant temperature: 650℃
• Coefficient of friction: 0.50
• Operating temperature: 500℃
• Recommended film thickness: 2µm more
