TiAln coating

TiAln coating

By adding Al to TiN is coated with improved more abrasion resistance and heat resistance. When operating temperature exceeds 700℃, the Al component and oxygen are combined by frictional heat, and strong Al2O3 is generated on the outermost layer, contributing to further improvement of the lifetime.

Oxidation resistance/ Heat resistance improving carbide
Cutting tools/ Cold heading tool
Punching dies/ SUS machining die （mold for processing）

TiAln coating is recommended in this field

Wear resistance Heat resistance/oxidation resisitance Lubricity/slidability/low friction Cold press Cold forging Punching die Aparture mold Press fitting dies SUSprocessing mold Cutting tool High-speed cutting tool Carbide cutting tool Carbide tool Punch pin Die casting Trimming dies Film types of PVD coating

Feature

High hardness: TiN and TiCN has been achieved over Hv3000, and the wear resistance due to hardness has been greatly improved.
Heat-resistant: Achieved high heat resistance of 800℃ which exceeds CrN.

High adhesion hardening: Hv3,000
Heat resistance temperature: 800℃
Friction coefficient: 0.55
Operating temperature: 500℃
Recommended film thickness: 3µm or more
