TiCN-PVD coating

TiCN-PVD coating

This coating has improved hardness by adding carbon (C) to TiN . Since the film thickness is almost same as TiN , it can be easily adopted as a upgrade version of TiN.

Abrasion resistance/Burn-in resistance improvement
General cutting tools/Cold forging tool
Press dies/Punching dies

TiCN-PVD coating is recommended in this field

Cold pressCold forgingPunching dieAparture moldPress fitting diesCutting toolCarbide cutting toolPunch pinDie castingTrimming diesFilm types of PVD coating

Feature

High hardness

Increased to Hv2800 compared to Hv2300 for TiN

Seizure resistance

Seizure resistance is improved by adding slipperiness to TiN.

• Film hardness: Hv2,800
• Heat-resistant temperature: 400℃
• Coefficient of friction: 0.40
• Operating temperature: 500℃
• Recommended film thickness: 2µm more
